T5


T5 material is Tungsten series High-Speed Tool Steel.

Chemical composition of T5, T5 mechanical properties, T5 datasheet, T5 equivalent grade, Heat treatment and temperature process of T5.

  • Tags: T5,

T5 property sheet

T5 Spec.

Chemical Composition of T5

C 0.75~0.85
Si 0.20~0.40
Mn 0.20~0.40
P ≤0.030
S ≤0.030
Cr 3.75~5.00
Mo 0.50~1.25
V 1.80~2.40
W 17.5~19.0
Co 7.00~9.50

Mechanical Properties of T5

Rp0.2 (MPa) 785 (≥)
Rm (MPa) 574 (≥)
AKV (J) 23
A (%) 14
Z (%) 31
Hardness HBW 441

T5 shape and dimensions

T5 Round bar: 1mm-800mm
T5 Square bar: 10mm * 10mm-600mm *600mm
T5 Flat bar: Thickness:8mm-800mm Width:10mm to 1500mm
T5 Sheet or Plate: Thickness:3mm-80mm Width:1.5mm to 1500mm
T5 Strip or Coil: Thickness:0.1mm-3mm Width:1.5mm-1500mm
T5 Forgings: Shafts with flanks/pipes/tubes/slugs/donuts/cubes/other shapes
